M8 Female 3-Pin Shielded Cable Connector IP67

Name: M8 Female 3Pin Shielded Cable Connector IP67
Brand: KRONZ
Price: 1 USD

China M8 Female 3-Pin Shielded Cable Connector IP67 wholesale

Brand Name : KRONZ

Model Number : M0803F-2/SOOR

Certification : CE

Place of Origin : Guangdong, China

MOQ : 50 pieces

Payment Terms : T/T,Western Union,MoneyGram

Supply Ability : 100000 pieces per month

Delivery Time : 5-8 working days

Packaging Details : Polybag packing

Price : Negotiable

Type : Contact

Product name : M8 Pre-Assembled Cable Connector

Seal material : FPM/FKM

Insulation Resistance : ≥ 100MΩ

Contact resistance : ≤ 5mΩ

Pollution degree : 3

Ambient temperature : -25~+85℃

Degree of protection : IP67

Contact Now

M8 Connector with Shielded Cable Straight Female 3 Pin A Code PVC IEC 61076-2-104

This 3-Pin Female M8 Connector with shielded cable ensures reliable and noise-resistant signal transmission in compact industrial and automation environments. Designed for durability and performance, the shielded design minimizes electromagnetic interference (EMI), making it ideal for sensitive signal or sensor connections.

Features:

Connector Type: M8 Female, 3-Pin
Cable Type: Shielded for EMI protection
Applications: Sensors, actuators, robotics, fieldbus systems
Design: Compact, robust housing with secure screw-lock connection
Standards: Compatible with IEC 61076-2-104

Technical Parameters

Standard	IEC 61076-2-104
Contact nut material	Brass, nickle-plated
Contact surface material	Brass, gold-plated
Contact carrier material	PA, black
Housing material	TPU, black
Seal material	FPM/FKM
Insulation resistance	≥100MΩ
Contact resistance	≤5mΩ
Pollution degree	3
Ambient temperature	-25~+85℃
Mating cycles	>100
Degree of protection	IP67

Pin assignment	Wire color	Coding	Rated current	Voltage	Wire gauge	Cable outlet	Length	Model No.
	1=BN 3=BU 4=BK	A	3A	60V	3x0.25 (3x24AWG) PVC, shielded,black	Straight	2M	M0803M-2/SOOR
							5M	M0803M-5/SOOR
							10M	M0803M-10/SOOR

Product Images

M8 Female 3-Pin Shielded Cable Connector IP67

Product Dimension Drawing

M8 Female 3-Pin Shielded Cable Connector IP67
